Stainless steel Wire rope mesh

stainless steel Wire rope mesh Quick Details:

Usage: mainly rearing baby egg laying chicken
Material: Q195 low carbon steel or Q235 low carbon steel.
MOQ: 5 sets.
Type:A type.
Width: 2.3m-2.6m
Length: 1.6m-2.1m
Height: 1.5m
Package: in plastic bags and carbon box ; packed in wooden box and pullet
Deliver time: Within 25 days.

Properties Detail

stainless steel Wire rope mesh USS304 rope netting There are two types, one is woven types of steel cable mesh,the other is ferrule types of steel cable mesh.The woven types of steel cable mesh mateiral:stainless steel 304, 304L,316,316L.The structure of the steel calbe wire have 7x7 and 7x19. The steel cable wire diameter icludes 1/8", 3/32", 1/16", and 3/64", the standard mesh opening size includes 1"x1", 1-1/2"x1-1/2", 2"x2", 3"x3"and 4"x4".

Stainless steel Wire rope mesh Specifications:

Wire rope construction	Min breaking load (KN)	Wire rope diameter (mm)	Aperture
7x19	8.735	3.2	2"x2"
7x7	5.315	2.4	4"x4"
7x7	5.315	2.4	3"x3"
7x7	5.315	2.4	2"x2"
7x7	3.595	2.0	3"x3"
7x7	3.595	2.0	2"x2"
7x7	3.595	2.0	1.5"x1.5"
7x7	2.245	1.6	3"x3"
7x7	1.36	1.6	2"x2"
7x7	1.36	1.6	1.5"x1.5"
7x7	1.36	1.6	1"x1"
7x7	1.36	1.2	2"x2"
7x7	1.36	1.2	1.5"x1.5"
7x7	1.36	1.2	1"x1"
7x7	1.36	1.2	4/5"x4/5’
